TBMR

Recover machines directly from IBM Spectrum Protect backups

TBMR allows you to perform a bare machine recovery of your operating system, applications and data direct from an IBM Spectrum Protect (TSM) backup. The recovery is fast and can be fully automated to protect your critical systems from the consequences of physical damage, human error or system failure. You can recover your protected systems to any point in time provided by TSM.

Simulated recoveries can be scheduled which fully automates the creation of the recovered machine and then runs test scripts to verify integrity and functionality.

Recovery schedules can be set up months in advance and planned so that the entire server infrastructure is tested within the desired time frame. The recovery machines are held in an isolated network and can be released after every simulation so storage is not permanently required.

Detailed reporting of each step of the recovery process highlights any problems encountered and provides an audit trail of successful results to provide assurance that DR procedures are effective.

TBMR is re-sold globally by IBM and its channel partners and is currently available for Windows, Linux, Solaris and AIX operating systems. TBMR is the recommended Spectrum Protect bare metal recovery solution.

See how TBMR integrates with the Cristie Virtual Appliance.

Traingles background image

OS Support

With support for the latest and legacy Windows, Linux, AIX and Solaris operating systems. Protect your entire estate with our trusted Spectrum Protect recovery solution.

Dissimilar Environments

With our unique dissimilar environemnt technology, you can recover to any physical, cloud or virtual environment.

Automation

In a disaster recovery scenario, you don’t have time to sit and recover each server manually. TBMR supports fully automated recoveries via the Cristie Virtual Appliance or standalone.

Solution Highlights

  • Restore Spectrum Protect instantly to physical, hypervisor and cloud environments, including Azure and AWS
  • Leverage existing investment and restore Spectrum Protect without additional management or infrastructure
  • Recovered server is identical to original, including data, operating system and applications
  • Recover multiple servers simultaneously and rapidly to meet agreed RTOs
  • Managed using the simple and intuitive Cristie Virtual Appliance (VA)
  • Scheduled automated recovery simulations with full reporting to satisfy regulations
  • Supports system recovery, migration and replication for Linux and AIX on IBM Power Systems
  • Restore from Spectrum Protect for Virtual Environments (formerly TSM for VE)

Product Support

Type Product Product Version Cristie From To Notes
Operating System Solaris 9 TBMR 8.3 8.5

Only supported on SPARC platforms.

Operating System Solaris 10 TBMR 8.3
Operating System Solaris 11 TBMR 8.3
Operating System Windows Desktop 7 TBMR 8.3
Operating System Windows Desktop 8.1 TBMR 8.3
Operating System Windows Desktop 10 TBMR 8.3

Support up to version 1903.

Operating System Linux (Intel) Red Hat Enterprise Linux 5 TBMR 8.3
Operating System Linux (Intel) Red Hat Enterprise Linux 6 TBMR 8.3
Operating System Linux (Intel) Red Hat Enterprise Linux 7 TBMR 8.3
Operating System Windows Server 2019 TBMR 8.5
Operating System Windows Server 2016 TBMR 8.3
Operating System Windows Server 2012 R2 TBMR 8.3
Operating System Solaris 11.4 TBMR 8.3

Only supported on SPARC platforms.

Operating System AIX 6.1 TBMR 8.3

POWER 7, 8 and 9 supported.

Operating System AIX 7.1 TBMR 8.3

POWER 7, 8 and 9 supported.

Operating System AIX 7.2 TBMR 8.3

POWER 7, 8 and 9 supported.

Operating System Windows Server 2008 R2 TBMR 8.3
Operating System Windows Server 2012 TBMR 8.3
Operating System Linux (Intel) Ubuntu 16.04 LTS TBMR 8.3
Operating System Linux (Intel) Ubuntu 14.04 LTS TBMR 8.3
Operating System Linux (Intel) SUSE Linux Enterprise Server 15 TBMR 8.3
Operating System Linux (Intel) SUSE Linux Enterprise Server 12 TBMR 8.3
Operating System Linux (Intel) SUSE Linux Enterprise Server 11 TBMR 8.3
Operating System Linux (Intel) SUSE Linux Enterprise Server 10 TBMR 8.3 8.5
Operating System Linux (Intel) Oracle Linux 7 TBMR 8.3
Operating System Linux (Intel) Oracle Linux 6 TBMR 8.3
Operating System Linux (Intel) CentOS Linux 7 TBMR 8.3
Operating System Linux (Intel) CentOS Linux 6 TBMR 8.3
Operating System Linux (Intel) CentOS Linux 5 TBMR 8.3 8.6.1
Operating System Linux (PPC) SUSE Linux Enterprise Server 15 TBMR 8.3

POWER 9 (Little Endian) supported.

Operating System Linux (PPC) Ubuntu 14.04 LTS TBMR 8.3

POWER 8 (Little Endian) supported.

Operating System Linux (PPC) Ubuntu 16.04 LTS TBMR 8.3

POWER 8 (Little Endian) and 9 (Little Endian) supported.

Operating System Linux (PPC) Ubuntu 18.04 LTS TBMR 8.3

POWER 8 (Little Endian) and 9 (Little Endian) supported.

Operating System Linux (PPC) SUSE Linux Enterprise Server 12 TBMR 8.3

POWER 8 (Little Endian) and 9 (Little Endian) supported.

Operating System Linux (PPC) SUSE Linux Enterprise Server 11 SP4 TBMR 8.3

POWER 7, 8 (Big Endian) and 9 (Big Endian) supported.

Operating System Linux (PPC) CentOS Linux 7 TBMR 8.3

POWER 7, 8 (Little Endian and Big Endian) and 9 (Little Endian) supported.

Operating System Linux (PPC) CentOS Linux 6 TBMR 8.3

POWER 7 and 8 (Big Endian) supported.

Operating System Linux (PPC) Red Hat Enterprise Linux 7 TBMR 8.3

POWER 7, 8 (Little Endian and Big Endian) and 9 (Little Endian) supported.

Operating System Linux (PPC) Red Hat Enterprise Linux 6 TBMR 8.3

POWER 7 and 8 (Big Endian) supported.

Operating System Linux (Intel) Ubuntu 18.04 LTS TBMR 8.3
Third Party Client IBM Spectrum Protect 8.1.7 TBMR 8.6
Third Party Client IBM Spectrum Protect 8.1.6 TBMR 8.4
Third Party Client IBM Spectrum Protect 8.1.4 TBMR 8.3
Third Party Client IBM Spectrum Protect 8.1.2 TBMR 8.3
Third Party Client IBM Spectrum Protect 8.1.0 TBMR 8.3
Third Party Client IBM Tivoli Storage Manager (TSM) 7.1 TBMR 8.3
Third Party Client IBM Tivoli Storage Manager (TSM) 6.4 TBMR 8.3 8.5
Third Party Client IBM Tivoli Storage Manager (TSM) 6.3 TBMR 8.3 8.5
Virtualisation VMware vSphere 6.7 TBMR 8.3
Virtualisation VMware vSphere 6.5 TBMR 8.3
Virtualisation VMware vSphere 6.0 TBMR 8.3
Virtualisation VMware vSphere 5.5 TBMR 8.3
Virtualisation Microsoft Hyper-V 2019 TBMR 8.5
Virtualisation Microsoft Hyper-V 2016 TBMR 8.3
Virtualisation Microsoft Hyper-V 2012 R2 TBMR 8.3
Virtualisation Microsoft Hyper-V 2012 TBMR 2.2
Virtualisation Microsoft Hyper-V 2012 TBMR 8.3
Virtualisation Microsoft Hyper-V 2008 R2 TBMR 8.3
Virtualisation Amazon Elastic Compute Cloud (EC2) TBMR 8.3
